Bring your thermography program in‑house.
ThermalSync takes your team from thermal image to corrective action. Inspect on your schedule, let images sort themselves, and turn every exception into a work order.
- Works with the camera you own
- Built for NFPA 70B
- CMMS work orders
Illustration: a thermal image of a three-pole breaker where the phase B line-side connection runs 41°F hotter than the other phases. ThermalSync assigns the image to its asset, flags an exception, and creates a work order.
Inspect when it works for you.
No contractor calendar. No shutdowns. Capture thermal images while equipment runs under normal load, one asset or an entire line at a time.
- Your electricians, your knowledge. The people who know the equipment do the inspection.
- Under normal operating load. No meticulous plan to catch every asset in one day.
- Frequencies you set. Monthly, quarterly, or annually, by asset criticality.
Outside contractor
0 day · whole facility
Your team with ThermalSync
0 days · as production allows
- Assets inspected
- 0/212
- Lines shut down
- 0
- Contractor days
- 0
As simple as an upload.
Capture the way you always have, then upload the whole route at once. ThermalSync’s patent-pending method assigns every image to the right asset and component. No renaming, no folders, no sorting.
-
K37
-
-
-
-
C2
-
-
-
-
A9
-
-
-
-
M4
-
-
-
- Reading asset tags
- Associating images
- Generating radiometric images
- Extracting visible images
- Ready for review
-
K37
Cooling Tower Motor
Roof Units
Motor · Side
Driven end
Terminals
-
C2
MCC-3 · Bucket 4B
Boiler Room
Line side
Load side
Contactor
-
A9
Transformer A
East Building
Primary
Secondary
Tank
-
M4
VFD-7
Line 3
Heatsink
Enclosure
Output
- Images assigned
- 0/248
- Assets
- 0/36
- Sorted by hand
- 0
Exceptions turn into action.
Assisted fault finding flags what’s running hot in the context of each component. Track every exception to resolution in ThermalSync, or send it to your CMMS as a work order.
- Facility-wide exception codes, severity, and status
- Thermal and visible images attached to every finding
- Re-inspect to prove the fix worked
Phase B connection overheating
MCC-3 › Main breaker › Line side
Peak 189.2°F ΔT +41°F vs Phase A
In ThermalSync
- OpenFlagged by assisted fault finding
- In progressAssigned to J. Ruiz · Electrical
- ResolvedLug re-torqued · verified 148.3°F
In your CMMS
Work orderPhase B connection overheating
MCC-3 · Priority high
Syncing with ThermalSync
A PDF for everyone who needs one.
Most of your team works from live data. When insurers, auditors, or leadership want it on paper, generate a polished Inspection Report in one click.
- Every image, measurement, and exception
- Severity criteria and inspector notes
- Numbered, signed off, and audit-ready
Built for NFPA 70B.
NFPA 70B now requires routine thermographic inspections of electrical equipment under load. ThermalSync schedules them by asset, documents every finding and fix, and keeps the record ready for insurers and auditors.
- Efficient
- Your electricians run the whole inspection. No second crew on standby.
- Convenient
- Inspect under normal load, spread across the year.
- Complete
- Images, loads, findings, and fixes, ready for any audit.
See the drift before the failure.
Every inspection adds a reading to each component’s temperature history. Spot the slow climb, act early, and prevent faults before they happen.
Phase B line-side lug · rise over ambient
- Reading
- 150.1°F
- ΔT vs Phase A
- +2°F
- Trend
- Stable
Built for the people who own uptime.
Whether you run the maintenance program or the plant floor, ThermalSync gives you the view you need.
Maintenance managers
Own the program.
- Cut contractor spend, keep the know-how
- Track every exception to closure
- Stay ready for NFPA 70B audits
- One account, many locations
Plant managers
Keep lines running.
- Inspect under normal load, no shutdowns
- Catch faults before unplanned downtime
- Schedule repairs into planned changeovers
- See plant health at a glance
See your own equipment through ThermalSync.
Book a 30-minute demo built around your equipment and inspection routine, or send us a message. A real person answers, quickly.
